ESBE ball valve with motor drive MBA 121 - 1"

ESBE Ball valve with motor drive MBA 121 - 1" -43100200

The ESBE motorized ball valve MBA 121, size 1", is designed for precise control of fluid flow in heating, cooling and industrial applications. The valve has a reliable servo drive with a fast movement of 40 seconds per 90°, which allows easy installation and operation thanks to the 230 V AC electrical connection. The stainless steel construction ensures long service life and corrosion resistance.

Technical specifications

• Valve type: Motorized ball valve
• Nominal size (DN): 25 (1")
• Flow rate (Kv): 60 m³/h
• Operating temperature: -10 to +110 °C
• Maximum pressure (PN): 32 bar
• Connection size: 1" internal thread
• Body material: Stainless steel
• Drive power supply: 230 V AC
• Power consumption: 8.5 VA
• 90° rotation time: 40 seconds
• Drive torque: 10 Nm
• Protection class: IP44

Advantages

• Fast and precise flow control
• Durable stainless steel design
• Easy installation and maintenance
• Higher pressure resistance (PN32)
• Universal use in heating, cooling and industry
• Reliable motor drive with low consumption

Function

• Automatic valve opening and closing
• Flow control according to the set signal
• Limitation and control of pressure losses in the system
• Manual adjustment possible thanks to accessible controls

Example of use

• Flow control in heating systems of family houses
• Valve control in air conditioning and refrigeration systems
• Automation of industrial technological operations
• Control of heating and hot water distribution in commercial buildings

- - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Order code: 43100200
