HONEYWELL weekly wire thermostat T3

Honeywell T3 weekly wire thermostat

The T3 series thermostats are very easy to install and are
fully compatible with a wide range of boilers and systems.
Intuitive control and management of heating based on time
program and temperature, including many other functions,
makes the T3 series of thermostats also popular with end thermostats
users.

T3 wire
Standard wire design
for the option to install instead
existing wire thermostat

• Modern, minimalist design is a suitable accessory for every type of household
• The option of installing a thermostat between the desktop version or wall mounting is ideal for both new applications and reconstructions.
• The backlight of the display makes it easy to read the displayed values in all lighting conditions
• Preset programs: Individual program for each day of the week or combined program 5/2 (working days / weekend).
• The thermostat allows the setting of 4 independent time periods for each day of the week for maximum comfort.
• The set desired room temperature is always displayed.
• The thermostat has an integrated frost protection in OFF mode with a minimum set temperature of 5 ° C - so the pipe can never freeze in winter
• The thermostat displays warning messages that help detect faults.
• Button for changing the temperature independently of the current program with a duration of 1 hour.
• Automatic time setting for "summer time".
• Wireless switching unit with simple LED indication and control button
• The thermostat is compatible with heat sources controlled by a potential-free contact or equipped with OpenTherm® (T3M) communication

TECHNICAL PARAMETERS

• Display range: 0 - 50°C
• Dimensions: 136 x 97 x 26 mm
• Time display: 24 or 12 hour AM / PM
• Minimum program time step: 10 minutes
• Temperature sensor: 10k Ohm at 25°C
• Power supply: 2 x 1.5 V (AA) battery
• Temperature setting range: from 5°C to 35°C (5°C frost protection is active when switched off)
