HONEYWELL filter with pressure reducing valve FK74CS

HONEYWELL Filter with pressure reducing valve FK74CS

PrimusPlus F74CS backwash filters ensure a continuous supply of filtered water. These filters contain a backwash filter and a pressure regulator integrated in one fitting. The fine filter screen reduces the amount of foreign particles in the water, such as rust fragments, hemp fibers or sand grains. The F74CS PrimusPlus filters can be equipped with an automatic backwash unit Z74S-AN, which ensures the filter screen is flushed at a preset interval.

TECHNICAL DATA:

• Product certification: DIN/DVGW certified
• body material: synthetic materials
• medium: water
• pressure setting range: 1.5 - 6 bar
• connection: external thread
• maximum medium temperature: 30°C
• nominal pressure: PN16
• transparent filter sump: yes
• sieve fineness: 100µm
• Flow capacity Kvs: 5.9
• backwash filter screen: a no
• Mounting position: horizontal or vertical

Filter information:

• The filter contains an integrated pressure reducing valve.
• Patented backwash system - enables fast and high-quality water purification
• adjustable next flush date indicator
• Bayonet connection allows for simple and quick installation of the automatic flushing unit
• large sieve area
• impact-resistant clear transparent filter sump allows easy inspection of filter contamination
• integrated pressure gauge in the filter

The FK74CS drinking water filter is suitable for use in systems where maximum comfort is required. Thanks to the built-in pressure reducing valve, there is no need to install additional elements in the water supply system.

Order code: FK74CS1AA
